Standard w/Single Hand-operated winch for raising and lowering tower.
Mecc Alte brushless four-pole generator.
60-gallon fuel tank.
Four touch point level system with agg-jacks coupled with two outriggers.
120V AC Duplex GFCI.
12V Group24 start battery.
Powder-coat finish.
Compact transverse trailer with leaf spring axle.
Hinged back panel for engine access.
Standard 2-inch ball hitch or hitch for 2.5-inch pintle hook.
Technical Specifications:
Physical
Deployed footprint 129 × 111 in (327 × 281cm), L × W Operating height Max. 24 ½ ft (7.5m) Min. 7 ¾ ft (2.4m) Travel height 93 in (237cm) Weight Operating Approx. 1965 lb (891kg) Shipping Approx. 1580 lb (717kg)
Tongue weight Dry 80 lb (36kg)
Lights480-watt LEDs 350-watt LEDs Metal halides Lamps* Four 480 W fixtures Four 350 W fixtures Four 1000 W lamps Luminosity** 57,800 lm per fixture 49,000 lm per fixture 110,000 lm per lamp 231,200 lm total 196,000 lm total 440,000 lm total
Power system Engine type Tier 4 Final diesel, 3-cylinder, 4-cycle Engine speed* 1800 rpm @ 60 Hz or 1500 rpm @ 50 Hz Generator type Brushless, class H Sound level 68 dB @ 23 ft (7m) at max. load Battery Maintenance-free AGM, 12 Vdc, 550 CCA
Mitsubishi L3E Kubota D1005 Kubota D1105 Maximum power output* 12.2 hp (9.1 kW) 13.1 hp (9.8 kW) 15.4 hp (11.5 kW)
Displacement* 58.09 in3 (952 cm3) 61.08 in3 (1001 cm3) 68.53 in3 (1,123 cm3) Fuel tank capacity 60 gal (227 L) 60 gal (227 L) 60 gal (227 L)
Output power Output* 6 kW or 8 kW Voltage* 120 Vac or 240 Vac Amperage 50 A @ 120 V, 25 A @ 240 V Frequency* 60 Hz or 50 Hz Voltage regulation ±6%, no load to full load
*Depending on model
**Continuous intensity for LEDs, initial intensity for metal halides
